Bobcat E26 Compact Excavator
Bobcat E26 Compact Excavator
Bobcat E26 Compact Excavator Information
The Bobcat® E26 compact excavator (mini excavator) features minimal tail swing to reduce the risk of damage to your machine and surrounding objects. With its compact size and excellent flotation, the Tier 4-compliant E26 easily maneuvers established lawns, crowded jobsites and sensitive surfaces. The E26 is also available in a long arm model.
Engine
| EMISSIONS TIER (EPA) | Tier 4 |
| ENGINE FUEL | diesel |
| MAXIMUM GOVERNED RPM | 2,500 rpm |
| HORSEPOWER | 24.8 hp |
| TURBOCHARGED ENGINE | not-available |
| OPTIONAL HORSEPOWER | n/a |
Performance
| OPERATING WEIGHT | 6,489 lb |
| WEIGHT CLASS | 2.9 t |
| TRAVEL SPEED | 3.2 mph |
| TRAVEL SPEED - HIGH | 3.2 mph |
| TRAVEL SPEED - LOW | 1.8 mph |
| ARM DIGGING FORCE | 3,547 lbf |
| BUCKET DIGGING FORCE | 5,652 lbf |
| RATED LIFT CAPACITY | 2359 lb |
| LIFT RADIUS | 118 in |
| BOOM SWING - LEFT | 70° |
| BOOM SWING - RIGHT | 55° |
| MAXIMUM DIG DEPTH | 9.5 ft |
| MAXIMUM DUMP HEIGHT | 10.4 ft |
Capacities
| FUEL TANK | 9.1 gal |
Hydraulic System
| AUXILIARY STD FLOW | 14.2 gal/min |
| AUXILIARY PRESSURE | 2,611 psi |
Dimensions
| LENGTH | 170.4 in |
| WIDTH | 61 in |
| HEIGHT | 96 in |
| HEIGHT WITH OPERATOR CAB | 96 in |
| REACH @ MAXIMUM HEIGHT | 16 ft |
List of Features
| AIR CONDITIONING | Not Available |
| CAB ENCLOSURE | optional |
| CAB HEATER | not-available |
| HEATER / AIR CONDITIONING | optional |
| TAIL SWING TYPE | minimal |
| ENGINE SHUTDOWN | standard |
| AUXILIARY HYDRAULICS | standard |
| SECONDARY AUXILIARY HYDRAULICS | optional |
| RUBBER TRACK | standard |
| SELECTABLE AUXILIARY HYDRAULIC FLOW | not-available |
| ANGLE BLADE | not-available |
| QUICK TACH SYSTEM | standard |
*New price, if shown, is Suggested List Price (SLP). Current national programs are subtracted. SLP and/or final actual sales price will vary depending on options or accessories selected.
REQUEST A QUOTE
| Manufacturer | Bobcat |
| Category | Compact Excavators |
| Model | E26 |
| Condition | New |
| Year | 2021 |
| Horsepower | 24.8 hp |
