MultiQuip MVC82VHW Plate Compactor
MultiQuip MVC82VHW Plate Compactor Information
Recognized as the industry standard for compacting granular soils and asphalt.
- Reliable engine with Honda GX160 offering easy start-up and low oil shutdown for durability.
- Cyclonic pre-cleaner captures most airborne contaminants for engine protection and extended service life.
- Anti-vibration handle dramatically reduces operator fatigue and increases productivity.
- Solid, high-strenght steel base plate for durability.
- Tubular steel roll bar protects engine components and provides central lifting point.
- Sealed belt cover keeps dirt and rocks out extending belt life.
- Open base plate design makes for easier removal of dirt and rock build-up.
- Cog-tooth belt drive enables longer life compared to conventional V-belts.
- Front mounted exciter assembly allows for easy service access.
- Removable, tool-free water tank can easily be refilled to 11.5 quart capacity
|OPERATING WEIGHT||181 lb 82 kg|
|TRAVEL SPEED||72 ft 22 m (forward speed per minute)|
|CENTRIFUGAL FORCE||3080 lbf 13.7 kN|
|EXCITER SPEED||5600 VPM|
|FUEL TANK||0.31 gal 1.17 L (fuel consumption per hour)|
|WATER TANK CAPACITY||11.5 qt 10.88 L|
|LENGTH||36 in 914 mm|
|WIDTH||17.7 in 450 mm|
|HEIGHT||39.5 in 1003 mm|
|PLATE SIZE||17.7 x 22.4 in 450 x 570 mm|
*New price, if shown, is Suggested List Price (SLP). Current national programs are subtracted. SLP and/or final actual sales price will vary depending on options or accessories selected.
